Dali Cable

Screened Multi-Conductor Cable – Suitable for Audio, Control, Instrumentation & Building Management Systems (BMS)

Features

• Conductor: 16 AWG (19 x 29) Flexible Bare Copper Wire

• Insulation: Halogen-Free Flame Retardant (HFFR / LSZH)

  • Core 1: Black

  • Core 2: Red

  • Core 3: White

  • Core 4: Green

  • Core 5: Brown

  • Core 6: Blue

  • Core 7: Orange

  • Core 8: Yellow

  • Core 9: Purple

  • Core 10: Grey

  • Core 11: Pink

  • Core 12: Tan

  • For cables with more than 12 cores: Black with White serial numbers

• Drain Wire: 24 AWG (7 x 32) Tinned Copper

• Screen: Aluminum/Polyester with 100% Coverage

• Rip Cord: Nylon Yarn

• Sheath Material: Flame-Retardant Halogen Free (HFFR / LSZH)

• Standard Colour: Purple

• Standard Put-Up Length: 305 meters

Standards & Compliance

• BS EN 50290-2

• IEC 60228, IEC 61034

• IEC 60754-1 & 2

• IEC 60332-3-24

• RoHS Compliant
